30W Electric Vibration Motor Concrete Vibrator Brushless DC Motor Adjustable Excitation Force and Speed 12V/24V 0-4000rpm

Description
This electric vibration motor has a fast speed and can provide sufficient power to your device. At the same time, the product has low noise and will not cause discomfort to other people. Finally, the product is lightweight, small in size, and does not take up space when used. This product is a suitable choice for your work and life.

Specification
Material: Aluminum Alloy, Copper
Surface Treatment: Plastic Spraying
Motor Type: Brushless DC Motor
Assembly Required: Yes
Mount Type: Free Standing
Rated Voltage: 12/ 24V
Rated Power: 30W
Frequency: 50Hz
Protective Grade: IP65
Maximum Speed: 4000RPM
Protection Class: Closed
Insulation Level: F
Number of Items: 1
Noise: 60 db
Power Source: Electric Energy
Engine Cooling Type: Air Cooling
Starter System: Hand Start
Mount Type: Free Standing
Gross Weight: 1kg/ 2.2lbs
Net Weight: 0.85kg/1.87lbs
Package Size: 20*15*10 cm/ 7.87*5.9*3.93inch
Product Size: 11.9*7.6*7cm/ 4.68*2.99*2.75inch

Package Included
1*Electric Vibration Motor
1*English Manual

Key Features
Sturdy and Durable: The exquisite aluminum alloy, copper, and spray molding process make the product resistant to corrosion, rust, wear, oxidation, and has fast heat dissipation and temperature rise ability, so it can withstand the test of time well.

Adjustable Excitation Force: The angle of the eccentric block of the vibration motor is adjustable, allowing for adjustable excitation force. Therefore, it can meet various requirements.

Adjustable Speed: The convenient and powerful governor allows you to freely adjust the speed within the range of 0-4000rpm to meet different work needs, with high cost-effectiveness.

Effortless Cleaning: The smooth surface allows you to easily remove residues with a soft towel and water.

Simple Operation: The simple structure and detailed English instructions allow you to complete the installation and start using in a short time.

Strong Power: The 30W brushless DC high-speed motor, with a maximum speed of 4000rpm, high-performance bearing, and high-precision rotor endow the product with strong power, which can work normally even under heavy loads and meet various commercial purposes.

Safety Guard: F insulation level, enclosed protection level, high-temperature resistant pure copper coil (248 ℉), air-cooled heat dissipation mode, and the O-ring with fully enclosed structure design and dust and moisture proof function can better ensure safety during operation, so you can use it with confidence.

Quality Service: We stand behind all our guests and look forward to assisting you with your purchase. It is our pleasure to answer your confusion and questions. The end of the story between us is definitely not “we sell and you buy”.

Details

Solid Base: The protruding base of the product can make the machine more stable and less prone to shaking during operation.

Round Corners: Compared to traditional square corners, cover design can better care for your skin.

Notes
1.The motor voltage is 12/24V, please do not connect high voltage power. The ambient temperature for use of this product should not exceed 60 ℃.
2.Before use, please fix the motor with screws to avoid safety accidents, and remember to regularly check the tightness of the installation screws and dust on the surface of the vibrating motor.
3.To meet the installation needs of different customers, our motors do not include plugs.
4.When adjusting the excitation force, please adjust the adjustable eccentric blocks at both ends to the same direction and angle. Be sure to secure the motor and ensure that the voltage is 12/24V. After adjustment, the screws should be firmly fixed to prevent them from falling off during vibration.
5.In order to ensure the normal installation and use of the motor, please confirm the motor model and installation size before purchasing.
6. It should be noted that in many cases, the amplitude of a vibration motor is also affected by other factors, such as the stiffness, damping coefficient, material character…
